1280x1024 igwefoto igwefoto igwefoto na 75mm (55mm, 35m) athermalized lens
Nlereanya | SG-TCM12N2-75 | SG-TCM12N2-55 | SG-TCM12N2-35 | |
Ihe mmetụta | Ihe mmetụta onyonyo | VOx microbolometer adịghị mma | ||
| Mkpebi | 1280 x 1024 | |||
| Nha Pixel | 12μm | |||
| Mpaghara Spectral | 8~14μm | |||
| Netwọk | ≤50mK @ 25℃, F#1.0 | |||
oghere | Ogologo Focal | 75mm Igwe oghere ikuku | 55mm Igwe oghere ikuku | 35mm Igwe oghere ikuku |
| Ngwa anyaBugharịa | N/A | N/A | N/A | |
| DBugharịa | 4x | 4x | 4x | |
| F Uru | F1.0 | F1.0 | F1.0 | |
| FOV | 11.7° x9.4° | 15.9° x12.7° | 24.8°x19.9° | |
Vidiyo | Mkpakọ | H.265/H.264/H.264H | ||
| Sntapu | JPEG | |||
| Agba pseudo | Nkwado: ỌchaNa-ekpo ọkụ, Black Hot, Iron Red, Egwurugwu 1,Fulgurite, Egwurugwu 2, Fusion, Bluish Red, Amber, Arctic, Tint | |||
| Strems | MStream:25fps@(1280×1024) Sub iyi:25fps@(640×512),25fps@(352×288) | |||
Netwọk | NetwọkProtocol | IPv4/IPv6, HTTP, HTTPS, Qos, FTP, SMTP, UPnP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, DHCP, PPPoE, 802.1X, IP Filter | ||
| Mmekọrịta | Profaịlụ ONVIF S, Mepee API, SDK | |||
| Oke.Njikọ | 20 | |||
ọgụgụ isi | NNkịtị Omume | Nchọpụta ngagharị,Nchọpụta ọdịyo, esemokwu adreesị IP, ịnweta iwu na-akwadoghị, nchekwa nchekwa | ||
| IVS ọrụ | Kwado ọrụ ọgụgụ isi:Tripwire, Nchọpụta ngere gafere, mbanye, Nchọpụta ihe nlegharị anya. | |||
| Ọkụ Nchọpụta | Snkwado | |||
| Iinterface | Ethernet | 4PIN Ethernet ọdụ ụgbọ mmiri, 10M/100M onwe - mmeghari | ||
| HD-SDI(Nhọrọ) | 1ch HD-SDI | |||
| Abanye/Ọpụpụ | 1/1 | |||
| AudioIn/apụ | 1/1 | |||
| RS485 | Snkwado | |||
| Mkpebi | 50Hz: 25fps@(1280×1024) | |||
| EIS | Snkwado | |||
| NchekwaCike | Kaadị Micro SD, ruo 256G | |||
| Ịnye ọkụ | DC12V, 1A | |||
| Ọnọdụ ọrụ | -20°C~+60C/20% ruo 80%RH | |||
| Ọnọdụ Nchekwa | -40°C~+65Celsius C/20%ruo 95%RH | |||
| Akụkụ (L*W*H) | Ihe ruru. 194mm* 131mm * 131mm | Ihe ruru. 141mm*51mm*61mm | Ihe ruru. 130mm*51mm*61mm | |
| Ibu | Ihe ruru. 1.1kg | Ihe ruru.366g | Ihe ruru.435g | |
